Outdoor lighting 105 watt 12VAC Electronic Encapsulated Transformer MDL 316-0004

Alternative product: TA105WA12LED - Get more info here!

If you plan to upgrade your halogen fixture to LED bulbs we recommend that you use a transformer made for LED Bulbs and Dimming LED bulbs.

Outdoor lighting 105 watt 12VAC Electronic Encapsulated Transformer MDL 316-0004

More Views

Product Videos

Outdoor lighting 105 watt 12VAC Electronic Encapsulated Transformer MDL 316-0004

Name: Outdoor lighting 105 watt 12VAC Electronic Encapsulated Transformer MDL 316-0004
SKU: HD105-120
Price: 17.50 USD
Availability: InStock
Rating: 5 (6 reviews)

# HD105-120

2 Review(s) | Add Your Review

Outdoor lighting SL-728 Electronic 105watt bare wire replacement transformer. 120volt input, 12volt output. Compact easy to use design. Perfect for lighting applications. Dimmable with standard electronic dimmer. Similar to the MDL 316-0004, WH-1051E6A transformer, and the Anchorn Model no: AET-D1051. Use within water tight junction box.

Designer's Note

If you plan to upgrade your halogen fixture to LED bulbs we recommend that you use a transformer made for LED Bulbs and Dimming LED bulbs.

Ships Free by USPS 2-3 day from our parts department if 25 units or less are ordered. Do not order by air. Only use with Halogen Bulbs & Lamps

Availability: Ships in 2-Business day!

$17.50

Qty:

Specification Sheets

HD Transformer Spec Sheet

(Size: 75.7 KB)

Here to Help

Quality lighting can increase sales, security and property value.
Enjoy our video guides and how to's here

Details

Super small 120volt to 12volt completely encapsulated transformer. Output at 105watts max including line loss. Do not overload. Ships with 6" input and output leads. Please see specification sheet before you order. Similar to MDL 316-0004, WH-1051E6A. Electronic Transformer 105W 120V Input

Additional Information

Finishes	Black
Warranty	90 Days
Important Note	Ships Free by USPS 2-3 day from our parts department if 25 units or less are ordered. Do not order by air. Only use with Halogen Bulbs & Lamps
Primary Breaker	No
Secondary Breaker	No
Circuits	Single
Terminal Block	No
Dimmable	Any dimmer
Material	Plastic
Cross Reference Number	MDL 3160004, SL-728 105 watt, Anchorn Model no: AET-D1051, flextecbset 105, MDL Corp, mdl p/n 316-004, Tiella fixture 800RAL5MKN replacement transformer, TST-105. Eurofase 0089 105-Watt, Top Star TST-105W/120V, Topstar TST-105W/120V, Relco ETV 105 PF.1/110 RN1248/110
Approvals	ETL
UPC	190202205355
Max Load Wattage	105
Min Load Wattage	20
Input Voltage	120VAC
Output Voltage	12VAC
Electric Current Type	AC
Dimensions H x W x L (in)	1.12 X 4.26 X 2
