Details
EMS - EMCOD Outdoor Single Circuit Stainless Steel Series is a dimmable, magnetic, hard wire power supply, which can supply 12V or 24V, AC or DC voltage to any kind of low voltage fixtures: LED, Halogen, Xenon an so on. The boost tap on the primary side compensates a wire drop voltage on a long run and maintains a brightness of your lights. Primary manually reset circuit breaker on all products as a standard. Secondary protection is optional for AC and standard for all DC products.Two section bobbin provides complete insulation between primary and secondary sides. Encapsulated with polyester resin for whisper quiet operation. Small dimensions and weight saves space and lowers an installation cost. The outdoor enclosure rated NEMA 3R or IP24.
Additional Information
| Finishes | Stainless Steel |
|---|---|
| Warranty | 90 Days |
| Primary Breaker | Yes |
| Secondary Breaker | Yes |
| Circuits | Single |
| Terminal Block | No |
| Dimmable | Magnetic Dimmer - dimmer's minimum load must be maintained |
| Material | Stainless Steel |
| Cross Reference Number | Technomagnet SSC300S, SSX300S |
| Application | Low voltage outdoor LED lighting, Low voltage outdoor lighting |
| Approvals | cETLus |
| Max Load Wattage | 300 |
| Input Voltage | 120VAC |
| Output Voltage | 12VAC |
| Electric Current Type | AC |
| Dimensions H x W x L (in) | See Spec Sheet |
