Details
EMCOD ML MAG-LED Series transformers are a Revolutionary Compact, dimmable, low profile magnetic LED Driver on the market. The transformer core and special low drop voltage rectifier are designed to lower losses and make the ML series very efficient and energy saving with low temperature rise. All the ML drivers have primary and secondary self-reset thermal circuit breakers, can be fully loaded and has excelled load regulation. Input and output are lead wires.
Additional Information
Finishes | Black |
---|---|
Warranty | 90 Days |
Important Note | This AC unit can not be returned.Contact us for sensitive AIR orders |
Primary Breaker | Yes |
Secondary Breaker | Yes |
Circuits | Single |
Terminal Block | No |
Dimmable | Magnetic Dimmer - dimmer's minimum load must be maintained |
Material | Steel |
Cross Reference Number | Technomagnet MF10S, MF10S12, MF10S12AC |
Application | Low voltage LED lighting, Low voltage lighting |
Approvals | cETLus |
Max Load Wattage | 10 |
Input Voltage | 120VAC |
Output Voltage | 12VAC |
Electric Current Type | AC |
Dimensions H x W x L (in) | See Spec Sheet |
