Outdoor lighting HD60-120 60watt 12VAC Electronic Encapsulated Transformer

Name: Outdoor lighting HD60-120 60watt 12VAC Electronic Encapsulated Transformer
SKU: HD60-120
Price: 14.70 USD
Availability: InStock
Rating: 5 (3 reviews)

# HD60-120

1 Review(s) | Add Your Review

Outdoor lighting Electronic 60watt bare wire replacement transformer. 120volt input, 12volt AC output. Compact easy to use design. Perfect for lighting applications. Dimmable with standard electronic dimmer. Similar to WAC-Lighting-EN-1260-R-AR. and the High-Tec Electronic Products part number TMO60S 120 20-60W E235548 transformer, SL-518

Designer's Note

If you plan to upgrade your halogen fixture to LED bulbs we recommend that you use a transformer made for LED Bulbs and Dimming LED bulbs.

Ships Free by USPS 2-3 day from our parts department if 25 units or less are ordered. Do not order by air. Only use with Halogen Bulbs & Lamps

Availability: Typically ships in 2 business days!

$14.70

Qty:

Here to Help

Quality lighting can increase sales, security and property value.
Enjoy our video guides and how to's here

Details

Super small 120volt to 12volt AC completely encapsulated transformer. Output at 60watts max including line loss. Do not overload. Ships with 6" input and output leads. Please see specification sheet before you order.

Similar to/ and should work as a replacement for the following, check the physical size to insure it fits the space you have to mount it. Simlar wtih two wires in (black/White) and two output wires 12v AC.

WAC-Lighting-EN-1260-R-AR.

High-Tec Electronic Products part number TMO60S 120 20-60W E235548 transformer,

SL-518

Ortek model CK-1260b-1

Novitronix 9801AR

Wang House Model WH-601E6A-3B,

OrTek110v to12v 60W,

Kichler K1058wt transformer

Electronic DR16S black transformer

IF in doubt send us a photo

Additional Information

Finishes	Black
Warranty	90 Days
Important Note	Ships Free by USPS 2-3 day from our parts department if 25 units or less are ordered. Do not order by air. Only use with Halogen Bulbs & Lamps
Primary Breaker	No
Secondary Breaker	No
Circuits	Single
Terminal Block	No
Dimmable	Any dimmer
Material	Plastic
Cross Reference Number	SL-518 60 watt, SL-518, WAC-Lighting-EN-1260-R-AR, WAC EN-12P-AR, TMO60S 120 12-60W, TST-60, Top Star TST-60W/120V, Topstar TST-60W/120V, Ortek model CK-1260b-1, Novitronix 9801AR, Wang House Model WH-601E6A-3B, Electronic transformer DR16s, Splendor King EE055
Approvals	ETL
UPC	190202205379
Max Load Wattage	60
Min Load Wattage	10
Input Voltage	120VAC
Output Voltage	12VAC
Electric Current Type	AC
Dimensions H x W x L (in)	7/8" X 1-3/8" X 2-7/8"
